CGMA 105
Dual-band GNSS/ GPS
Antenna Module
The CGMA 105 antenna is a circularly polarized high gain antenna used for satellite-based communications such as GPS and GNSS. It is designed to be mounted directly on a PCB. Additional circuitry to apply phases in each port can be added.
Typical applications include:
- Enhanced GPS/GNSS satellite communications
- Any device including automotive for location detection service
This antenna delivers best in class antenna gain technology for satellite navigation systems such as GNSS to support both L1 and L2/E5b bands at 1575.42MHz and 1223.0 MHz. Satellite navigation applications of today demand higher circular gain than ever before. Higher gain antennas with high circularity are necessary to achieve better position detection for these next generation satellite-based position detection systems. By using its patented antenna technology, SkyMirr is able to build higher gain and low AR (Axial Ratio) solutions as compared to currently available antennas.
The CGMA105 antenna has been carefully designed to work equally well in both the L1 band and the L2 band. This allows for better position detecting as the world requires more precise location detection services in Automotive, IoT, Military, and more applications.
Other features of the CGMA 105 include:
- RHCP gain 2.3 to 4.6 dBic
- RoHS compliant
Additional circuitry to provide phases in each antenna port may be necessary to achieve circular polarization in radiation. For further services including the circuit design, please contact the SkyMirr sales office at sales@skymirr.com
